  • Painful Oracle Connectivity Problems

    I’ve spent the better part of this week wrestling with Oracle connectivity issues, and figured I’d share a few things I’ve discovered.

    A recent BizTalk application deployment included an orchestration that does a simple update to an Oracle table. Instead of using the Oracle adapter, I used .NET component and the objects in the System.Data.OracleClient .NET framework namespace. As usual, everything worked fine in the development and test environments.

    Upon moving to production, all of a sudden I was seeing the following error with some frequency:

    Logging failure … System.InvalidOperationException: Timeout expired. The timeout period elapsed prior to obtaining a connection from the pool. This may have occurred because all pooled connections were in use and max pool size was reached.
    at System.Data.ProviderBase.DbConnectionFactory.GetConnection(DbConnection owningConnection)
    …

    Yowza. The most common reason for this occuring is failing to properly close/dispose a database connection. After scouring the code, I was positive that this wasn’t the case. After a bit of research, I came across the following two Microsoft .NET Framework hotfixes:

    So in a nutshell, bad database connections are by default, returned to the connection pool. Nice. I went ahead and applied this hotfix in production, but still saw intermittent (but less frequent) occurences of the error above.

    Next, I decided to turn on the SQL/Oracle performance counters so that I could actually see the pooling going on. There are a few counters that are “off” by default (including NumberOfActiveConnections and NumberOfFreeConnections) and require a flag in the application configuration file. To add these counters, go to the BTSNTSvc.exe.config file, and add the following section …

    <system.diagnostics>
    <switches>
      <add name="ConnectionPoolPerformanceCounterDetail"
           value="4"/>
    </switches>
  </system.diagnostics>

    Now, on my BizTalk server, I can add performance counters for the .NET Data Provider for Oracle and see exactly what’s going on.

    For my error above, the most important counter to initially review is NumberofReclaimedConnections which indicates how many database connections were cleaned up by the .NET Garbage Collector and not closed properly. If this number was greater than 0, or increasing over time, then clearly I’d have a connection leak problem. In my case, even under intense load, this value stayed at 0.

    When reviewing the NumberOfFreeConnections counter, I noticed that this was usually 0. Because my database connection string didn’t include any pooling details, I wasn’t sure how many connections the pool allocated automatically. As desperation set in, I decided to tweak my connection string to explicitly set pooling conditions (new part in bold):

    User Id=useracct1;Password=secretpassword;
   Data Source=prod_system.company.com;
   Pooling=yes;Max Pool Size=100;Min Pool Size=5;

    Once I did this, my counters looked like my picture above, with a minimum of 5 connections available in the pool. As I type this (2 days after applying this “fix”), the problem has yet to resurface. I’m not declaring victory yet since it’s too small of a sample size.

    However, given the grief that this has caused me, I’m tempted to switch from the System.Data.OracleClient to the System.Data.Odbc objects where I’ve had previous success and never seen this error in production. My other choice is give up my dream of using the API altogether and use the BizTalk Oracle adapter instead. Thoughts?

    To add insult to my week of Oracle connectivity hell, I’ve noticed that the Oracle adapter for a DIFFERENT application has been spitting this message out with greater occasion …


    Failed to send notification : System.AccessViolationException: Attempted to read or write protected memory. This is often an indication that other memory is corrupt.

    Naturally the message in the Event Log doesn’t tell me which send/receive port this is associated with because that would make troubleshooting less exciting. Anyone else see this rascal when using the Microsoft Biztalk Adapters for Enterprise Applications? I’ve also see it on occasion with my .NET code solution.

    All of this is the reason I missed the Los Angeles BizTalk Server 2006 R2 launch event this week. I’m still bitter. However, I’m told that bets were made at the event as to whether I’d blog more or less while out on paternity leave in a week or two, so it’s nice to know they were thinking of me! Stay tuned.

    Technorati Tags: ,

  • How to Distinguish BizTalk Schema Record Nodes

    I recently came across a newsgroup post discussing distinguishing fields in an auto-generated SQL Adapter schema, and after a bit of investigation, came up with a way to easily distinguish schema records.

    Now Jan Eliasen gave a perfectly good response to the newsgroup post, and helpfully pointed to his blog post on how to flip the default “records” to “elements” for easier manipulation.

    This however got me thinking as to whether the restriction on distinguishing record types was a tool limitation, or compiler/engine related. If you try to distinguish a record type, the “Promoted Properties” window doesn’t enable the “Add” button. Given that a “record” is really just an XSD element, and that often auto-generated schemas build all the nodes as records, this limitation sometimes screws you. So, I opened my XSD schema in the VS.NET XML Editor instead of the BizTalk Editor.

    I then manually added a new “distinguished field” to the “properties” collection of the schema. After saving, and then opening the schema once more in the BizTalk Editor, voila, it now shows up as a distinguished field in the “Promoted Properties” window.


    To prove that this isn’t some sort of trickery, I then processed a message through the BizTalk engine, stopped by send port, and observed the context properties of my message. Sure enough, my “record” was properly distinguished and accessible.

    I got a little frisky and wondered if I could also solve the age-old problem of distinguishing repeating nodes. The Editor tool prevents this activity because there’s no way to designate which index of the repeating node you want. The standard solution is to promote/distinguish in an inbound pipeline instead. However, what if you KNEW that you only wanted the first repeating node as the distinguished value? Could you also manually add this distinguished field to the schema?

    Alas, despite numerous varieties of syntax, I couldn’t get the compiler to approve of this. I consistently got the compile time error saying The promoted property field or one of its parents has Max Occurs greater than 1. Only nodes that are guaranteed to be unique can be promoted as property fields.. I tried using “position()=1” or a “[1]” indexer, and either way, I struck out.

    But, at least now I have a simple way to distinguish records, so it’s not a total loss.

    Technorati Tags:

  • Issue When Serializing BizTalk Auto-Generated Schemas To .NET Objects

    Yesterday a co-worker of mine was having issues serializing an auto-generated BizTalk schema into a .NET object. We found an obscure fix that solved the problem.

    In Darren’s Professional BizTalk Server 2006 book, he’s a proponent of working with serializable classes (instead of messages) where possible. In our case, my buddy Prashant was doing some mass Oracle table updates using data retrieved from the BizTalk Siebel adapter. Instead of having countless “Oracle Insert” messages, we discussed simply turning the Siebel messages into .NET objects and using a helper class to do one big transactional insert.

    So, he took the Siebel adapter schemas, ran them through xsd.exe, and ended up with a nice .NET object representing all the nodes in the schema. However, upon doing the XLANGMessage “RetrieveAs” operation, he got a gnarly error (actual type names removed) stating:

    Cannot use XLANGMessage.RetrieveAs to convert message part part with type [SampleNamespace].[TypeName]+QueryEx2Response to type QueryEx2Response.”
    …
    Exception type: InvalidCastException
    Source: Microsoft.XLANGs.Engine
    Target Site: System.Object RetrieveAs(System.Type)
    …
    Unable to generate a temporary class (result=1).
    error CS0030:
    Cannot convert type ‘Customer_Complaint_Case_BCResultRecord[]’ to
    ‘Customer_Complaint_Case_BCResultRecord’
    error CS0029:
    Cannot implicitly convert type
    ‘Customer_Complaint_Case_BCResultRecord’ to
    ‘Customer_Complaint_Case_BCResultRecord[]’

    Ouch. Well from reading that, clearly there looks like a problem serializing that “BCResultRecord” array. After doing a quick web search, I came across a newsgroup post discussing the same serialization problem we hit. The solution? Add a temporary “attribute” to the unbounded item to force the xsd.exe tool to properly deal with array types. So, before the change, my offending piece of the Siebel-generated XSD looked like this:

    <xsd:complexType name="Customer_Complaint_Case_BCResultRecordSet">
    <xsd:sequence>
      <xsd:element minOccurs="0" maxOccurs="unbounded"
	  name="Customer_Complaint_Case_BCResultRecord"
	  type="BizObj:Customer_Complaint_Case_BCResultRecord" />
    </xsd:sequence>
  </xsd:complexType>

    When running xsd.exe, the generated type looked like this …

    public partial class QueryEx2Response {

    private Customer_Complaint_Case_BCResultRecord[][]
	    Customer_Complaint_Case_BCResultRecordSetField;

    [System.Xml.Serialization.XmlArrayItemAttribute
	(typeof(Customer_Complaint_Case_BCResultRecord),
	 Namespace="http://schemas.microsoft.com/Business_Objects",
	  IsNullable=false)]
    public Customer_Complaint_Case_BCResultRecord[][]
                   Customer_Complaint_Case_BCResultRecordSet {
        get {
         return this.Customer_Complaint_Case_BCResultRecordSetField;
        }
        set {
         this.Customer_Complaint_Case_BCResultRecordSetField = value;
        }
    }
}

    Here’s where the problem was. So, I *temporarily* tweaked the schema to add the temporary attribute …

    <xsd:complexType name="Customer_Complaint_Case_BCResultRecordSet">
    <xsd:sequence>
      <xsd:element minOccurs="0" maxOccurs="unbounded"
	  name="Customer_Complaint_Case_BCResultRecord"
	  type="BizObj:Customer_Complaint_Case_BCResultRecord" />
    </xsd:sequence>
    <xsd:attribute name="temp" type="xsd:string" />
  </xsd:complexType>

    NOW, after re-running xsd.exe, my generated type looked like this …

    public partial class QueryEx2Response {

    private Customer_Complaint_Case_BCResultRecordSet[]
	Customer_Complaint_Case_BCResultRecordSetField;

    [System.Xml.Serialization.XmlElementAttribute
	("Customer_Complaint_Case_BCResultRecordSet")]
    public Customer_Complaint_Case_BCResultRecordSet[]
                  Customer_Complaint_Case_BCResultRecordSet {
        get {
         return this.Customer_Complaint_Case_BCResultRecordSetField;
        }
        set {
         this.Customer_Complaint_Case_BCResultRecordSetField = value;
        }
    }
}

    You can see how the generated class now recognizes the “BCResultRecordSet” object as an array, vs. using a double-array of type “BCResultRecord.” Also, the metadata about accessor changed from being a XmlArrayItemAttribute to a XmlElementAttribute. Once this change was made, everything worked perfectly.

    I was able to successfully switch the schema back to it’s original form (sans “temporary attribute”), and the serialization still worked fine. The key was adding that temporary attribute for the creation of the serializable class only. You don’t need to keep this temporarily attribute in the schema after that.

    I suspect that this situation would arise for many of the auto-generated schemas from the BizTalk adapters (Siebel, Oracle, Peoplesoft, SQL Server etc). It’s quite nice to deal with these messages as pure .NET objects, but watch out for tricky serialization issues.

    Technorati Tags:

  • New Microsoft Whitepaper on BizTalk Ordered Delivery

    Interesting new white paper from Microsoft on maintaining ordered delivery across concurrent orchestrations (read online or download here).

    Specifically, this paper identifies an architecture where you receive messages in order, stamp them with a sequence number in a receive pipeline, process them through many parallel orchestration instances, and then ensure resequencing prior to final transmission. The singleton “Gatekeeper” orchestration does the resequencing by keeping track of the most recent sequence number, and then temporarily storing out-of-sequence messages (in memory) until their time is right for delivery.

    One thing that’s wisely highlighted here is the considerations around XLANG/s message lifetime management. Because orchestration messages are being stored (temporarily) in an external .NET object, you need to make sure the XLANG engine treats them appropriately.

    Good paper. Check it out.

    Technorati Tags:

  • Securely Storing Passwords for Accessing SOA Software Managed Services

    One tricky aspect of consuming a web service managed by SOA Software is that the credentials used in calling the service must be explicitly identified in the calling code. So, I came up with a solution to securely and efficiently manage many credentials using a single password stored in Enterprise Single Sign On

    A web service managed by SOA Software may have many different policies attached. There are options for authentication, authorization, encryption, monitoring and much more. To ease the confusion on the developers calling such services, SOA Software provides a clean API that abstracts away the underlying policy requirements. This API speaks to the Gateway, which attaches all the headers needed to comply with the policy and then forwards the call to the service itself. The code that a service client would implement might look like this …

    Credential soaCredential =
    new Credential("soa user", "soa password");

//Bridge is not required if we are not load balancing
SDKBridgeLBHAMgr lbhamgr = new SDKBridgeLBHAMgr();
lbhamgr.AddAddress("http://server:9999");

//pass in credential and boolean indicating whether to
//encrypt content being passed to Gateway
WSClient wscl = new WSClient(soaCredential, false);
WSClientRequest wsreq = wscl.CreateRequest();

//This credential is for requesting (domain) user.
Credential requestCredential =
    new Credential("DOMAIN\user", "domain password");

wsreq.BindToServiceAutoConfigureNoHALB("unique service key",
    WSClientConstants.QOS_HTTP, requestCredential);

    The “Credential” object here doesn’t accept a Principal object or anything similar, but rather, needs specific values entered. Hence my problem. Clearly, I’m not going to store clear text values here. Given that I will have dozens of these service consumers, I hesitate to use Single Sign On to store all of these individual sets of credentials (even though my tool makes it much simpler to do so).

    My solution? I decided to generate a single key (and salt) that will be used to hash the username and password values. We originally were going to store these hashed values in the code base, but realized that the credentials kept changing between environments. So, I’ve created a database that stores the secure values. At no point are the credentials stored in clear text in the database, configuration files, or source code.

    Let’s walk through each component of the solution.

    Step #1

    Create an SSO application to store the single password and salt used to encrypt/decrypt all the individual credential components. I used the SSO Configuration Store Application Manager tool to whip something up. Then upon instantiation of my “CryptoManager”, I retrieve those values from SSO and cache them in the singleton (thus saving the SSO roundtrip upon each service call).

    Step #2

    I need a strong encryption mechanism to take the SOA Software service passwords and turn them into gibberish to the snooping eye. So, I built a class that encrypts a string (for design time), and then decrypts the string (for runtime). You’ll notice my usage of the ssoPassword and ssoSalt values retrieved from SSO. The encryption operation looks like this …

    /// <summary>
/// Symmetric encryption algorithm which uses a single key and salt
/// securely stored in Enterprise Single Sign On.  There are four
/// possible symmetric algorithms available in the .NET Framework
/// (including DES, Triple-DES, RC2, Rijndael/AES). Rijndael offers
/// the greatest key length of .NET encryption algorithms (256 bit)
/// and is currently the most secure encryption method.
/// For more on the Rijndael algorithm, see
/// http://en.wikipedia.org/wiki/Rijndael
/// </summary>
/// <param name="clearString"></param>
/// <returns></returns>
public string EncryptStringValue(string clearString)
{
    //create instance of Rijndael class
    RijndaelManaged RijnadaelCipher = new RijndaelManaged();
    //let add padding to ensure no problems with encrypted data
    //not being an even multiple of block size
    //ISO10126 adds random padding bytes, vs. PKCS7 which does an
    //identical sequence of bytes
    RijnadaelCipher.Padding = PaddingMode.ISO10126;

    //convert input string to a byte array
    byte[] inputBytes = Encoding.Unicode.GetBytes(clearString);

    //using a salt makes it harder to guess the password.
    byte[] saltBytes = Encoding.Unicode.GetBytes(ssoSalt);

    //Derives a key from a password
    PasswordDeriveBytes secretKey =
	    new PasswordDeriveBytes(ssoPassword, saltBytes);

    //create encryptor which converts blocks of text to cipher value
    //use 32 bytes for secret key
    //and 16 bytes for initialization vector (IV)
    ICryptoTransform Encryptor =
	    RijnadaelCipher.CreateEncryptor(secretKey.GetBytes(32),
                 secretKey.GetBytes(16));

    //stream to hold the response of the encryption process
    MemoryStream ms = new MemoryStream();

    //process data through CryptoStream and fill MemoryStream
    CryptoStream cryptoStream =
	    new CryptoStream(ms, Encryptor, CryptoStreamMode.Write);
    cryptoStream.Write(inputBytes, 0, inputBytes.Length);

    //flush encrypted bytes
    cryptoStream.FlushFinalBlock();

    //convert value into byte array from MemoryStream
    byte[] cipherByte = ms.ToArray();

    //cleanup
    //technically closing the CryptoStream also flushes
    cryptoStream.Close();
    cryptoStream.Dispose();
    ms.Close();
    ms.Dispose();

    //put value into base64 encoded string
    string encryptedValue =
        System.Convert.ToBase64String(cipherByte);

    //return string to caller
    return encryptedValue;
}

    For decryption, it looks pretty similar to the encryption operation …

    public string DecryptStringValue(string hashString)
{
    //create instance of Rijndael class
    RijndaelManaged RijnadaelCipher = new RijndaelManaged();
    RijnadaelCipher.Padding = PaddingMode.ISO10126;

    //convert input (hashed) string to a byte array
    byte[] encryptedBytes = Convert.FromBase64String(hashString);

    //convert salt value to byte array
    byte[] saltBytes = Encoding.Unicode.GetBytes(ssoSalt);

    //Derives a key from a password
    PasswordDeriveBytes secretKey =
	    new PasswordDeriveBytes(ssoPassword, saltBytes);

    //create decryptor which converts blocks of text to cipher value
	//use 32 bytes for secret key
    //and 16 bytes for initialization vector (IV)
    ICryptoTransform Decryptor =
	    RijnadaelCipher.CreateDecryptor(secretKey.GetBytes(32),
                 secretKey.GetBytes(16));

    MemoryStream ms = new MemoryStream(encryptedBytes);

    //process data through CryptoStream and fill MemoryStream
    CryptoStream cryptoStream =
	    new CryptoStream(ms, Decryptor, CryptoStreamMode.Read);

    //leave enough room for plain text byte array by using length of
	//encrypted value (which won't ever be longer than clear text)
    byte[] plainText = new byte[encryptedBytes.Length];

    //do decryption
    int decryptedCount =
        cryptoStream.Read(plainText, 0, plainText.Length);

    //cleanup
    ms.Close();
    ms.Dispose();
    cryptoStream.Close();
    cryptoStream.Dispose();

    //convert byte array of characters back to Unicode string
    string decryptedValue =
        Encoding.Unicode.GetString(plainText, 0, decryptedCount);

    //return plain text value to caller
    return decryptedValue;
}

    Step #3

    All right. Now I have an object that BizTalk will call to decrypt credentials at runtime. However, I don’t want these (hashed) credentials stored in the source code itself. This would force the team to rebuild the components for each deployment environment. So, I created a small database (SOAServiceUserDb) that stores the service destination URL (as the primary key) and credentials for each service.

    Step #4

    Now I built a “DatabaseManager” singleton object which upon instantiation, queries my SOAServiceUserDb database for all the web service entries, and loads them into a member Dictionary object. The “value” of my dictionary’s name/value pair is a ServiceUser object that stores the two sets of credentials that SOA Software needs.

    Finally, I have my actual implementation object that ties it all together. The web service proxy class first talks to the DatabaseManager to get back a loaded “ServiceUser” object containing the hashed credentials for the service endpoint about to be called.

    //read the URL used in the web service proxy; call DatabaseManager
ServiceUser svcUser =
    DatabaseManager.Instance.GetServiceUserAccountByUrl(this.Url);

    I then call into my CrytoManager class to take these hashed member values and convert them back to clear text.

    string bridgeUser =
    CryptoManager.Instance.DecryptStringValue(svcUser.BridgeUserHash);
string bridgePw =
    CryptoManager.Instance.DecryptStringValue(svcUser.BridgePwHash);
string reqUser =
    CryptoManager.Instance.DecryptStringValue(svcUser.RequestUserHash);
string reqPw =
    CryptoManager.Instance.DecryptStringValue(svcUser.RequestPwHash);

    Now the SOA Software gateway API uses these variables instead of hard coded text.

    So, when a new service comes online, we take the required credentials and pass them through my encryption algorithm to get a hash value, then add a record in the SOAServiceUserDb to store the hash value, and that’s about it. As we migrate between environments, we simply have to keep our database in sync. Given that my only real risk in this solution is using a single password/salt to hash all my values, I feel much better knowing that the critical password is securely stored in Single Sign On.

    I would think that this strategy stretches well beyond my use case here. Thoughts as to how this could apply in other “single password” scenarios?

    Technorati Tags:

  • BizTalk Ordered Delivery Gotcha

    One of my colleagues recently lost a bit of work because of a tricky “gotcha” with messages going through an ordered delivery channel in BizTalk Server.

    For someone viewing suspended messages in the BizTalk Administration Console, there is no obvious way to identify a suspended port as an ordered delivery port. In the screenshot below, I’ve stopped an ordered delivery send port, and sent five messages through.

    As you can see, the console only shows a “1 Count” of suspended ports. That’s clearly not the case. How do I see the REAL count of messages? I’ve got two choices. First, I can double-click the suspended port and switch to the “Messages” tab.

    Another way to see the messages is to right-click the suspended instance and select “Show Messages.”

    So what’s the gotcha? My buddy wanted to delete a few of the messages in the queue, so he right-clicked the messages he wanted to delete, and chose “Terminate Instance.”

    To his absolute horror, this action terminated all the messages in the suspended port instance, instead of his expected goal of eliminating only choice messages. Yowza. If you turn on the “Stop sending subsequent messages on current message failure” flag on the port, you CAN eliminate a message, BUT, it’s only the front-most message in the queue that blocking up the pipe. To see this, I flipped that flag on, and sent a number of messages in. Now if I right-click the single suspended instance, I have the option to “Find Failed Message.”

    The message that is shown afterwards can be selected and deleted in this scenario. So, I was hoping that if I manipulate the query in the Admin Console, I too could delete ANY message in the queue. Alas, even searching by “Message ID” and returning a single instance from the queue (as the “Failed Message” processing does), doesn’t afford me the chance to delete any message of my choosing. All I can still do is “Terminate Instance” instead.

    So the takeaway is …

    • Warn administrators to be careful when deleting suspended instances associated with ordered delivery ports. They may THINK they are deleting a single instance, but in fact, are deleting dozens or hundreds of underlying messages.
    • You cannot terminate individual messages that are queued up for ordered delivery.

    Technorati Tags:

  • BizTalk SSO Configuration Data Storage Tool

    If you’ve been in the BizTalk world long enough, you’ve probably heard that you can securely store name/value pairs in the Enterprise Single Sign-On (SSO) database. However, I’ve never been thrilled with the mechanism for inserting and managing these settings, so, I’ve built a tool to fill the void.

    Jon Flanders did some great work with SSO for storing configuration data, and the Microsoft MSDN site also has a sample application for using SSO as a Configuration Store, but, neither gave me exactly what I wanted. I want to lower the barrier of entry for SSO since it’s such a useful way to securely store configuration data.

    So, I built the SSO Config Store Application Manager.

    I can go ahead and enter in an application name, description, account groups with access permissions, and finally, a collection of fields that I want to store. “Masking” has to do with confidential values and making sure they are only returned “in the clear” at runtime (using the SSO_FLAG_RUNTIME flag). Everything in the SSO database is fully encrypted, but this flag has to do with only returning clear values for runtime queries.

    You may not want to abandon the “ssomanage” command line completely. So, I let you export out the “new application” configuration into the SSO-ready format. You could also change this file for each environment (different user accounts, for instance), and then from the tool, load a particular XML configuration file during installation. So, I could create XML instances for development/test/production environments, open this tool in each environment, and load the appropriate file. Then, all you have to do is click “Create.”


    If you flip to the “Manage” tab of the application, you can set the field values, or delete the application. Querying an application returns all the necessary info, and, the list of property names you previously defined.

    If you’re REALLY observant, and use the “ssomanage” tool to check out the created application, you’ll notice that the first field is always named “dummy.” This is because if every case I’ve tested, the SSO query API doesn’t return the first property value from the database. Drove me crazy. So, I put a “dummy” in there, so that you’re always guaranteed to get back what you put in (e.g. put in four fields, including dummy, and always get back the three you actually entered). So, you can go ahead and safely enter values for each property in the list.

    So how do we actually test that this works? I’ve included a class, SSOConfigHelper.cs (slightly modified from the MSDN SSO sample) in the below zip file, that you would included in your application or class library. This class has the “read” operation you need to grab the value from any SSO application. The command is as simple as:

    string response = SSOConfigHelper.Read(queryName, propertyName);

    Finally, when you’re done messing around in development, you can delete the application.

    I have plenty of situations coming up where the development team will need to secure store passwords and connection strings and I didn’t like the idea of trying to encrypt the BizTalk configuration file, or worse, just being lazy and embedding the credentials in the code itself. Now, with this tool, there’s really no excuse not to quickly build an SSO Config Store application and jam your values in there.

    You can download this tool from here.

    Technorati Tags:

  • BizTalk 2006 R2 Launch in Los Angeles

    If you’re in the Los Angeles area, check out the registration for the BizTalk 2006 R2 Launch Event. I just signed up. I’ll be the guy in the back heckling Marty and Chris with taunts such as “SOA is dead!”, and “BizTalk killed my parents!”. Good fun.

    Technorati Tags:

  • My BizTalk vNext Wish List

    Congrats to the Connected Systems Division for getting BizTalk Server 2006 R2 out the door. Now that we’re done with that, here’s my humble “wish list” for BizTalk Server vNext. I realize that development is well under way, but, hopefully some of these requests can make it in.

    Design Tools

    • High level modeling tool. Nothing the team doesn’t know already, but I want a tool/view that let’s me architect the BizTalk solution at a broader level. Much like the BizTalk Server 2006 Administration Console introduced “application management”, I want a similar metaphor for “application architecture.”
    • Modeling tools that support industry standards. The BizTalk team has done a great job in embracing industry standards for developed artifacts (e.g. XSD, XSLT, SOAP, WSDL, XML), and I’d love to see a similar embrace of the design environment. Specifically, UML and/or BPMN support in the above-mentioned higher level modeling toolset.

    BizTalk Administration

    • Option for subscriber throttling. I need to be able to pick any orchestration or any send port and tell the engine not to instantiate more than X number of them at one time. Many smart folks have come up with various solutions (e.g. singletons, ordered delivery, etc), but I can’t see why it’s too technically challenging to force the XLANG engine (or EPM) to verify running instances vs. throttle count prior to instantiating a new instance.
    • Stronger dependency visibility. I’d like to be able to open the BizTalk Administration Console, view a host, and see every artifact that uses it. Likewise, I’d like to be able to view a schema and see each map that references it. I need more ways to find out which artifacts have dependencies on others so that I can better plan application upgrades or retirements.
    • “Application” level permission controls. Right now, when our team adds someone to the “Operators” group, they have free reign over any application deployed in the environment. That makes me a tad nervous. Too easy to accidentally terminate someone else’s suspended messages, or see message content that they shouldn’t. I’d like the option to allow department-level administrators to own, manage and troubleshoot specific applications in the BizTalk environment.
    • Web-based Administration Console. While it’s fairly simple to do a “Admin only” install of BizTalk on a desktop machine, I’d appreciate a web-based management console that let’s me perform a subset of standard tasks. Easier to provide access to multiple administrators (only if the isolated ownership point above is enacted), and if you wanted to get fancy, you’d AJAX the UI and provide near-real-time updates of running and suspended instances without a manual refresh.
    • Better subscription analysis. It’s great that the Subscription Viewer is now part of the Admin Console, but I need more criteria to search for. For instance, I’d like to be able to search for any subscription built upon a particular message type. If I need to change a schema namespace, which subscriptions will it impact? Same with searching for subscriptions by port names, etc. Again it comes back to impact analysis of changes.
    • Additional subscription operators. Right now, I can’t create a subscription based on a field NOT existing in the schema. I can only do “exists”. I’d also like subscriptions based on “contains” where I could route messages (without orchestrations) where a “customer ID” contains a particular substring.
    • More health metrics in the Admin Console. Specifically, I would find it useful if there was a portion of the Administration Console where I would be notified if host throttling thresholds were approaching, if a particular application was backlogged, etc. I know that I can find out this information using performance counters, or MOM, but I’d like to have the Admin Console be more of a “one stop shop.”

    Adapters

    • Updated core adapters. It’d be great to refresh some of the core adapters with new capabilities. I’d like to see the FILE adapter support XPath-based file name tokens. If I want the output file name to contain a field from the message, it’d be much easier to manage this at the adapter level rather than introducing orchestrations or custom pipelines. For the SMTP adapter, it should be much easier to do dynamic addressing. To dynamically choose the “To:” address, I have to do an orchestration with a dynamic port. And instead of just setting the “To:” address, I also have to use the BRE or custom component to grab the SMTP Host, Subject, etc. Often, the only “dynamic” piece of the email is the address. Seems like lots of improvements are possible for the SQL adapter. I’d like an “after poll” process option (like the Oracle adapter), and support for querying tables/views instead of requiring a stored procedure (or updategram). Seems like the Oracle adapter has more features than the SQL Server one.
    • More browsing, less typing. One of the top 5 improvements in BizTalk 2006 was the addition of the “browse” button in the FILE ports. Why am I still typing URLs in the SOAP/HTTP ports, or typing settings for the SharePoint adapter? Why can’t we browse more settings instead of relying on me to inevitably type the values incorrectly?

    Development

    • Refresh auto-generated schemas. I love that I can update a “web reference” in Visual Studio.NET with no problem, but I absolutely dread changes to auto-generated BizTalk schemas (SQL stored procedure, Siebel business object, etc) since I have to walk through the Generate Schemas wizard again even for a simple update to the data source. I’d love to right click on the Oracle database view XSD schema, and choose “refresh schema from source” and have the update automatically taken care of.
    • Option to automatically GAC referenced assembly. I know that I could add post-build steps on my .NET component libraries which would GAC the component for me. But, how great would it be if the BizTalk project properties page had a choice to “GAC all referenced assemblies”?
    • Orchestration unit test. I don’t know how you’d implement this, but even a simple test of an orchestration process involves a full deploy, build ports, etc. Sometimes I would like a quick process logic test without going through the whole deployment production.
    • “Construct Blank Message” in orchestration. Seems that I often come across folks who use XmlDocument variables or maps to simply create a new, empty BizTalk orchestration message. For instance, I may want an empty message that I pass to the BRE, which in turn fills in all the fields I want. Or, I create an empty Oracle query schema, and use a distinguished field to actually set my query filter. I’d like a “construct blank message” which instantiates a message WITHOUT using a transform or “message1 = message2” assignment.

    That’s all I’ve got for now. Thoughts? Any of those requests seem outlandish?

    Technorati Tags:

  • Utilizing Spring.NET To Integrate BizTalk and SOA Software

    I recently had the situation where I wanted to reuse a web service proxy class for multiple BizTalk send ports but I required a unique code snippet specific to each send port.

    We use SAP XI to send data to BizTalk which in turn, fans out the data to interested systems. Let’s say that one of those SAP objects pertains to each of our external Vendors. Each consumer of the Vendor data (i.e. BizTalk, and then each downstream system) consumes the same WSDL. That is, each subscriber of Vendor data receives the same object type and has the same service operations.

    So, I can generate a single proxy class using WSDL.exe and my “Vendor” WSDL, and use that proxy class for each BizTalk send port. It doesn’t matter the technology platform of my destination system, as this proxy should work fine whether the downstream service is Java, .NET, Unix, Windows, whatever.

    Now the challenge. We use SOA Software Service Manager to manage and secure our web services. As I pointed out during my posts about SOA Software and BizTalk, each caller of a service managed by Service Manager needs to add the appropriate headers to conform to the service policy. That is, if the web service operation requires a SAML token, then the service caller must inject that. Instead of forcing the developer to figure out how to correctly add the required headers, SOA Software provides an SDK which does this logic for you. However, each service may have different policies with different credentials required. So, how do I use the same proxy class, but inject subscriber-specific code at runtime in the send port?

    What I wanted was to do a basic Inversion of Control (IOC) pattern and inject code at runtime. At its base, an IOC pattern is simply really, really, really late binding. That’s all there is to it. So, the key is to find an easy to use framework that exploits this pattern. We are fairly regular uses of Spring (for Java), so I thought I’d utilize Spring.NET in my adventures here.

    I need four things to make this solution work:

      • A simple interface created that is implemented by the subscribing service team and contains the code specific to their Service Manager policy settings.
      • A Spring.NET configuration file which references these implemented interfaces
      • A singleton object which reads the configuration file once and provides BizTalk with pointers to these objects

    A modified web service proxy class that consumes the correct Service Manager code for a given send port

    First, I need an interface defined. Mine is comically simple.

    public interface IExecServiceManager
    {
    bool PrepareServiceCall();
    }

    Each web service subscriber can build a .NET component library that implements that interface. The “PrepareServiceCall” operation contains the code necessary to apply Service Manager policies.

    Next I need a valid Spring.NET configuration file. Now, I could have extended the standard btsntsvc.exe.config BizTalk configuration file (ala Enterprise Library), but, I actually PREFER keeping this separate. Easier to maintain, less clutter in the BizTalk configuration file. My Spring.NET configuration looks like this …

    <object name=”http://localhost/ERP.Vendor.Subscriber2
    /SubscriberService.asmx”
    type=”Demonstration.IOC.SystemBServiceSetup.ServiceSetup, Demonstration.IOC.SystemBServiceSetup” singleton=”false”/>
    </objects>

    I created two classes which implemented the previously defined interface and referenced them in that configuration file.

    Next I wanted a singleton object to load the configuration file and keep in memory. This is what trigger my research into BizTalk and singletons a while back. My singleton has a primary operation called LoadFactory during the initial constructor …

    using Spring.Context;
    using Spring.Objects.Factory.Xml;
    using Spring.Core.IO;
    …
    private void LoadFactory()
    {
    IResource objectList = new FileSystemResource
    (@”C:\BizTalk\Projects\Demonstration.IOC\ServiceSetupObjects.xml”);
    //set private static value
    xmlFactory = new XmlObjectFactory(objectList);}

    Finally, I modified the auto-generated web service proxy class to utilize Spring.NET and load my Service Manager implementation class at runtime.

    using Spring.Context;
    using Spring.Objects.Factory.Xml;
    using Spring.Core.IO;
    using Demonstration.IOC.InterfaceObject;
    …
    public void ProcessNewVendor(NewVendorType NewVendor)
    {//get WS URL, which can be used as our Spring config key
    string factoryKey = this.Url;

    //get pointer to factory
    XmlObjectFactory xmlFactory =
    XmlObjectFactorySingleton.Instance.GetFactory();

    //get the implementation object as an interface
    IExecServiceManager serviceSetup =
    xmlFactory.GetObject(factoryKey) as IExecServiceManager;

    //execute send port-specific code
    bool responseValue = serviceSetup.PrepareServiceCall();

    this.Invoke(“ProcessNewVendor”, new object[] {
    NewVendor});
    }

    Now, when a new subscriber comes online, all we do is create an implementation of IExecServiceManager, GAC it, and update the Spring.NET configuration file. The other option would have been to create separate web service proxy classes for each downstream subscriber, which would be a mess to maintain.

    I’m sure we’ll come up with many other ways to use Spring.NET and IOC patterns within BizTalk. However, you can easily go overboard with this dependency injection stuff and end up with an academically brilliant, but practically stupid architecture. I’m a big fan of maintainable simplicity.

    Technorati Tags:
